The Yokogawa SSC10S Safety Control Unit is a duplexed safety control unit designed for V net applications and rack mounting. It offers robust performance and high reliability in safety-critical environments.
Features
Processor: MIPS R5000 Processor
Main Memory Capacity: 32 MB
Power Failure Protection: Battery backup with a protection time of 3 years at maximum/30°C or less (non-rechargeable)
Temperature Adaptability: Includes a fan unit for high-temperature environments (ambient temperature exceeds 50 °C)
Communications Interface:
V net interface: Dual-redundant
ESB bus interface: Dual-redundant
Safety Node Units: Connect up to nine safety node units per safety control unit using ESB bus coupler modules (SEC401) in slots 7 and 8
I/O Modules: Supports up to eight for each safety control unit, and up to 78 for each Safety Control System (SCS)
IRIG Interface (Optional): Connect a GPS for high-accuracy synchronization when using SOER functions of a digital input module
Communication Interface: RS-422
Time Code: IRIG-B000
Frame Time: 1 s
Bit Time: 10 ms
Power Requirements
Voltage Options:
100 to 120 V AC, 50 or 60 Hz
220 to 240 V AC, 50 or 60 Hz
24 V DC
Power Consumption:
SSC10S-S/SSC10D-S:
100 to 120 V AC model: 200 VA
200 to 240 V AC model: 230 VA
24 V DC model: 5.5 A
SSC10S-F/SSC10D-F:
100 to 120 V AC model: 240 VA
200 to 240 V AC model: 290 VA
24 V AC model: 7.0 A
Weight
Approximately 7.9 kg (for SSC10S-S)
Approximately 13.0 kg (for SSC10S-F)
Approximately 8.5 kg (for SSC10D-S)
Approximately 13.0 kg (for SSC10D-F)
Mounting
Rack Mounting:
SSC10S-S/SSC10D-S: Rack mounted with eight M5 screws
SSC10S-F/SSC10D-F: Rack mounted with twelve M5 screws
