SDV531-L63 | Yokogawa Digital Output Module | In Stock!!
Sku:SDV531-L63
Country Of Origin: Japan
Vendor: Yokogawa
Type: Digital Output Module
In stock!
100% Original and Authentic
100% Brand New, Ready to ship
Support Refund, 7X24h Service
Share
Product description
General Information
Model: SDV531 Description: Digital Output Module (8-channel, 24 V DC, module isolation) Suffix Codes:
L: Long distance type
6: With signal cable interface adapter and no explosion protection
3: With ISA Standard G3 and temperature (-20 to 70 °C)
Technical Specifications
Number of Output Channels: 8-channel, module isolation
Output Voltage: 24 V DC
Output Voltage Drop: 1 V maximum
External Power Supply Rating: 24 V DC, 5 A minimum
External Power Supply: 24 V DC +20% / -10%
Current Capacity: 5 A
Maximum Leak Current at Output Off Status: 1.6 mA
Output Format: Current source
Maximum Load Current: 0.6 A/output line (4.8 A in total output lines)
Minimum Load Current: 35 mA
Load Resistance Range: 40 to 685 Ω
Output Response Time: 30 ms maximum
Withstand Voltage: 2 kV AC between output signal lines and system for 1 minute (8-point input lines collectively connected, negative lines)
Current Consumption:
280 mA maximum (5 V DC)
140 mA maximum (24 V DC)
Weight:
Approx. 0.28 kg (For pressure clamp terminal block or MIL cable)
Approx. 0.34 kg (With dedicated signal cable interface adapter)
External Connections
Connection Types:
Pressure clamp terminal
MIL cable
Dedicated signal cable (AKB331, AKB651)
Additional Information
Operating Conditions:
Temperature Range: -20 to 70 °C
Humidity: 5-95% without condensation
Installation Notes:
When connecting SDV531 and SED4D terminal board using AKB331 dedicated signal cable, the withstand voltage is 500 V AC (between output signal lines and system). If MIL connector cables are used, the withstand voltage depends on their cable’s electrical specifications.
Number of output channels a user can use and maximum load current are restricted in case of SDV531-L□C.
Field Power Supply:
Recommended to float the field power supply for higher noise immunity.
If grounded, the system ground is connected to the field ground and is not isolated.
Option Codes
/B4S00: With pressure clamp terminal block for digital output (without surge absorber) [Model: STB4S-00]
/B4S10: With pressure clamp terminal block for digital output (with surge absorber) [Model: STB4S-10]
/B4D00: With dual-redundant pressure clamp terminal block for digital output (without surge absorber) [Model: STB4D-00]
/B4D10: With dual-redundant pressure clamp terminal block for digital output (with surge absorber) [Model: STB4D-10]
/PRP: With prevention pin of false insertion
/CCC01: With connector cover for MIL cable (for flat ribbon cable) [Model: SCCC01]
/CCC02: With connector cover for MIL cable (for discrete wire) [Model: SCCC02]
