The ICS Triplex T8451 is a TrustedTM Module specifically engineered for fault-tolerant control applications, ensuring a high degree of reliability and safety with its triple modular redundant (TMR) architecture. This module is well-suited for industries requiring critical control capabilities, such as oil and gas, chemicals, and power generation.
Key Specifications
Product Type: TrustedTM Module
System Supply Voltage: 20 to 32 VDC
Circuit Type: Fault tolerant, fully triplicated with optional line monitoring
Number of Outputs: 40 Channels
Independent Power Groups: 5 each of 8 outputs
Output Voltage:
Operational Range: 18 to 32 VDC
Measurement Range: 0 to 32 VDC
Maximum Withstanding: -1 to 40 VDC
Output Current:
Continuous: 2A per channel, limited to 8A per power group
Maximum Capacitance: Pre-release 3.5: 30-55uF
Flashing/pulsing current loads: Release 3.5 is recommended
Minimum On State Load Current: 50mA
Output Off State Resistance: 33 ohms
Output On State Resistance: 0.6 ohms
Output Protection: Electronic (latching) short circuit protection
