IC697MDL940 | GE 16-Point Digital Output Relay Module
Sku:IC697MDL940
Country Of Origin: USA
Vendor: GE
Type: Digital Output
In stock!
100% Original and Authentic
100% Brand New, Ready to ship
Support Refund, 7X24h Service
Share
Product description
Overview
The IC697MDL940 is a robust 16-point output relay module designed for the GE Fanuc 90-70 Series, renowned for its versatility and user-friendly operation. It is capable of switching between low to medium power loads such as lamps, contactors, and relays with ease. Each output relay is individually fused and suppressed with an RC snubber for enhanced reliability and noise reduction.
Configuration Options: Offers 8 points in Form C (each point isolated) and 8 points in Form A (divided into 2 groups with 4 points per group), providing flexibility based on application requirements.
Isolation: Provides 1500 volts isolation between any output and the backplane, and 500 volts isolation between Form C circuits or Form A groups.
Maximum Load Current: Supports up to 16 amps per module for resistive loads, with Form A groups handling up to 4 amps.
Voltage Ratings: Handles nominal voltages of 120/240 VAC or 5/24/125 VDC, accommodating diverse load types.
Response Time: Swift response times with 10 msec maximum for both On and Off operations, ensuring efficient switching performance.
Protection Mechanisms: Each output is protected by a 3 amp fuse and equipped with snubbers (R = 47 ohms, C = 0.015 µF) to suppress high frequency noise and enhance longevity.
Installation and Configuration: Mechanically keyed for accurate placement, with configuration achieved via MS-DOS or Windows programming software over Ethernet using TCP/IP protocol.
Field Wiring: Accepts wire sizes ranging from AWG #22 (0.36 mm²) to AWG #14 (2.1 mm²) on detachable terminal boards, facilitating easy installation and maintenance.
Technical Specifications
Switching Characteristics: Supports a maximum power of 480 VA for AC loads and 60 watts for DC loads.
Current Requirements: Draws 750 mA from the 5 V bus for operation.
Contact Life: Mechanical: 20 x 10^6 operations; Electrical: 10^5 operations at rated resistive load.
Environmental Considerations: Operates reliably in environments with temperatures ranging from 0°C to +60°C (32°F to 140°F).
The IC697MDL940 relay output module is an ideal choice for applications requiring reliable switching capabilities and robust performance within the GE Fanuc 90-70 Series PLC systems.
