The IC694MDL646 is a 16-Point, 24 Volt DC, Positive/Negative Logic Input module belonging to the GE Fanuc RX3i Series. This module provides 16 input points organized in 1 group with a common power input terminal. The ON and OFF response times for this module typically range around 1 millisecond. For detailed specifications, please refer to the IC694MDL646's website page.
Technical Information
Specifications:
Rated Voltage: 24 Vdc
Input Voltage Range: 0 to +30 Vdc
Inputs per Module: 16 (one group with a single common)
Isolation: Field to Backplane (optical) and to frame ground
250 Vac continuous; 1500 Vac for one minute
Input Current:
7 mA (typical) at rated voltage
Input Characteristics:
On–state Voltage: 11.5 to 30 Vdc
Off–state Voltage: 0 to +5 Vdc
On–state Current: 3.2 mA minimum
Off–state Current: 1.1 mA maximum
On Response Time: 1 ms typical
Off Response Time: 1 ms typical
Power Consumption: 5Vdc:
80 mA (all inputs on) from 5Vdc bus on backplane
Power Consumption: 24Vdc18:
125 mA from the Isolated 24Vdc backplane bus or from user supplied power
