The IC693CHS392 is a 10-slot Expansion I/O Base designed for the Series 90-30 PLC system by GE Fanuc. It extends the PLC's I/O capabilities for industrial applications, allowing seamless integration of additional modules.
Key Features:
I/O Expansion: Provides 10 additional module connection slots, enabling users to expand the PLC's I/O capacity.
Local I/O Expansion: Supports local I/O expansion within a distance of up to 50 feet, enhancing control under the monitoring of a single processor.
Connectivity: Equipped with a 25-pin female D-type I/O Bus Expansion connector for connecting to other baseplates.
Compatibility: Must be mounted in a CPU baseplate of a system with a CPU, either in a PLC or a Personal Computer with a PCI card interface.
CPU Limitations: The maximum number of expansion baseplates allowed depends on the type of CPU. CPUs 331, 340, and 341 support up to 4 baseplates, while CPUs 350 and higher allow up to 7.
Power Supply: Requires power supply calculated based on the baseplate's modules and local load. Power must be supplied to the expansion baseplate.
DIP Switch: Includes a Rack Number Selection DIP switch and requires connection to a common ground.
Intelligent Option Modules: Does not support PCM, ADC, BEM330, and CMM311 modules; these must be mounted in a CPU baseplate.
Technical Specifications:
Module Type: Expansion I/O Base
Baseplate Option: Expansion
Distance: Up to 50 feet
Number of Slots: 10
Dimensions: 17.44 x 5.12 x 5.59 in. (W x H x D)
Internal Power Used: 150 mA @ 5 VDC
The GE Fanuc IC693CHS392 Expansion I/O Base provides a reliable and flexible solution for expanding the I/O capabilities of Series 90-30 PLC systems. With its robust design, compatibility with various CPUs, and easy installation, it offers enhanced control and scalability for industrial automation applications.
