IO Bus
The Control Processor governs IO operations, located within the IO chassis, through an IO bus. An IO extender, also within the IO chassis, communicates with individual IO modules via a horizontal IO bus.
The Control Processor interfaces with the IO system via an IO bus, a flat cable vertically running in the cabinet. The IO bus is managed by the IO Bus Driver function, a component of the QPP module. Each IO chassis contains an IO extender module, IO-0001, connecting to the IO bus. This IO extender drives the Horizontal IO Bus, transmitting signals from the IO bus to the IO modules through a flat cable. The Horizontal IO bus backplane sits atop each IO chassis. It, along with the flat cables of the IO modules, is shielded by a sheet steel cover, ensuring optimal EMC/RFI immunity. The cover plate includes a paper strip for relevant process tagging to aid signal identification.
IO Modules
The IO modules adhere to European standard-size instrument card dimensions. They have a front panel height of 3 HE (3U) and a width of 4 TE (4 HP). Each IO chassis can accommodate up to 18 IO modules. Standard 32-pin DIN 41612F connectors equip all IO modules. Additionally, IO chassis feature an IO backplane with matching 32-pin connectors, employing key coding to prevent mis-insertion of IO modules.
Safety Manager offers a broad array of digital and analog input and output interfaces, each with distinct characteristics, catering to diverse field equipment requirements. Table 12 on the subsequent page enumerates the available input and output interfaces with Safety Manager.
