Two independent inputs for eddy-current type sensor systems.
Differential sensor inputs, galvanically separated from the power supply.
Input resistance: >100 kOhm
Input voltage range: 0 to -22 V DC
Input frequency range: 15 to 2000 Hz
Measuring Ranges:
Continuously adjustable with configuration software.
Smallest range: 0 to 400 mV
Largest range: 0 to 8000 mV
Output Characteristics:
Galvanically separated from all system voltages and system supply voltage.
Open and short-circuit proof.
Can be operated in parallel with other modules without interference.
Nominal voltage: -28 Volts DC
Available current: Nominal 20 mA / Maximum 35 mA
Dimensions:
PCB/EURO Card Format: According to DIN 41494 (100 x 160 mm).
Width: 30.0 mm (6 TE).
Height: 128.4 mm (3 HE).
Length: 160.0 mm.
Net Weight: Approximately 320 g.
Gross Weight: Approximately 450 g (including standard export packing).
Packing Volume: Approximately 2.5 dm³.
Space Requirements: 14 modules (28 channels) fit into each 19” rack.
Requirements on Configuration PC:
Configuration of modules is made via the RS 232 interface on the module front or via the RS 485 bus by means of a computer (laptop) with the following minimum specifications:
Processor: 486 DX, 33 MHz.
Interfaces: One free RS 232 interface (COM 1 or COM 2) with FIFO type 156550 UART.
Capacity of Fixed Disk: Minimum 5 MB.
Required Working Memory: Minimum 620 KB.
Operating System: MS DOS Version 6.22 or higher, or WIN® 95/98, or NT 4.0.
