Input Type: Voltage, current (2-wire or self-powered transmitters)
Input Channels: 16 differential input channels
Common Mode Rejection Ratio, dc to 60 Hz (500 Ω source imbalance): 70 dB
Common Mode Voltage, dc to 60 Hz: -6 to +5 V peak
A/D Converter Resolution: 16 bits (14 bits used)
Input Range:
0 to 5 V
1 to 5 V
0.4 to 2 V
4-20 mA (through 250 Ω)
Normal Mode Rejection Ratio, at 60 Hz: 32 dB
Normal Mode Filter Response: Single-pole RC, -3 dB @ 1 Hz
Maximum Normal Mode Input (differential inputs, no damage): ± 30 Volts
Crosstalk, dc to 60 Hz (channel-to-channel): 60 dB
Input Impedance (Voltage Inputs): > 10 MΩ powered
Maximum Input Voltage (any input referenced to common, no damage): ± 30 Volts
Input Scan Rate: 4 samples per second per channel. All channels sampled within a 250 ms window.
Hardware Accuracy (@ CMV = 0 V):
± 0.075% full-scale (23.5°± 2°C)
± 0.15% full-scale (0 to 50°C)
Transmitter Power Conditioning:
For MU-TAIH02, TAIH52, TAIH12, TAIH03, TAIH13, TAIH53: Resistor Current Limited, 145 Ω (not fused) for Class 1, Div 2 interfacing
For MU-TAIH22, TAIH23, & TAIH62: Individually Protected Current Limiting Circuits for Class 1, Div 2 interfacing. Maximum current: 30 mA, Minimum voltage: 23 V
(1) The low-side input connection is normally connected to system common by a wire jumper on the FTA. This can be removed by the user, subject to operating within the CMV specification.
