1771-OFE1 Allen Bradley 4-Channel Analogue Voltage Output Module
Sku:1771-OFE1
Country Of Origin: USA
Vendor: Allen Bradley
Type: Analog Output
In stock!
100% Original and Authentic
100% Brand New, Ready to ship
Support Refund, 7X24h Service
Share
Product description
Overview
The Allen-Bradley 1771-OFE1 is a PLC-5 analog output module. It converts binary-coded decimal (BCD) or binary values into analog signals. This module offers four individually isolated outputs, making it ideal for controlling motor speed controllers, valve positioners, or other devices requiring precise voltage control.
Key Features
Number of Channels: Four isolated differential outputs (1000V isolation)
Output Signal Ranges: ±10 VDC, 0-10 VDC, 1-5 VDC
Resolution: 12-bit Digital-to-Analog conversion
Data Format: BCD or natural binary
Backplane Power Consumption: 1.5 Amperes
Mounting: Rack mountable
Technical Specifications
Manufacturer: Rockwell Automation
Brand: Allen-Bradley
Part Number/Catalog No.: 1771-OFE1
Module Type: Analog output module
Number of Inputs & Outputs: 4 isolated (1000 Volt) differential channels
Data Format: BCD or natural binary
Voltage Range: 1-5 VDC, 0-10 VDC, ±10 VDC
Module Resolution: 12 bits
Accuracy: ±0.1% of full scale
Converter Setting Time: 0.8 ms
Internal Scan Rate: 8 ms (for BCD); 1.6 ms (for binary)
Backplane Current: 1.5 Amperes
Power Dissipation: 7.9 Watts
Thermal Dissipation: 26.9 BTU/hour
Wiring Arm: 1771-WH
Operating Temperature: 32 to 140°F (0 to 60°C)
Storage Temperature: -40 to 185°F (-40 to 85°C)
Vibration: 2g at 10-500 Hz
Shock: 30g operating
Diagnostics and Fault Protection
The module has a built-in self-check feature. It notifies users of any faults via a red fault indicator LED. Additionally, it has 1500V optoelectrical isolation, protecting against overvoltage conditions.
