170ADO34000 | Schneider Discrete Output Module | 16 O Solid State
Sku:170ADO34000
Country Of Origin: US
Vendor: Schneider
Type: Discrete Output
In stock!
100% Original and Authentic
100% Brand New, Ready to ship
Support Refund, 7X24h Service
Share
Product description
Manufacturer: Schneider
Product No.: 170ADO34000
Schneider 170ADO34000 discrete output module is part of the Modicon Momentum range, designed for distributed control architecture. It offers 16 discrete outputs with solid-state switch type, organized into 2 groups of 8 outputs each. The module operates at a discrete output voltage of 24V DC, with a current per channel of 0.5A. Each group can handle a current of 4A, while the entire module supports up to 8A.
The outputs are electronically protected against short-circuits and overloads. Surge current protection is provided, with a maximum surge current of 5A for 1 ms. The module ensures fast response times, with transitions between states occurring in 0.1 ms.
Isolation between channels and the bus is rated at 500V AC, ensuring safety and reliability. The module features 16 LEDs for channel status signaling, providing visual feedback on the operation of each output.
With a compact design, the module has dimensions of 125mm (width) x 47.5mm (depth) x 141.5mm (height) and weighs 0.21kg. It is suitable for various applications, including infrastructures, energy, material handling, and simple machine control.
Certified by CE, FM Class 1 Division 2, CSA, and UL, this module offers robust performance and compliance with industry standards. It is suitable for wall mount installations.
The Modicon Momentum platform offers a flexible, modular family of components that can be easily configured for a wide range of distributed I/O and control applications. With a simple snap-together design, the components can form versatile control systems or sub-systems.
Specifications
Range of Product: Modicon Momentum automation platform
Product or Component Type: Discrete output base DC
Group of Channels: 2 groups of 8 outputs
Discrete Output Number: 16
Discrete Output Type: Solid state switch
Discrete Output Voltage: 24V DC
Current per Channel: 0.5A
Maximum Leakage Current: 1mA at 24V DC
Surge Current: 5A for 1 ms
Maximum Voltage Drop: <0.5V at 0.5A
Response Time: 0.1 ms
Isolation Between Channels and Bus: 500V AC
Power Dissipation: 3.5W typical, 4.5W maximum
Local Signalling: 16 LEDs for channel status
Dimensions: 125mm (W) x 47.5mm (D) x 141.5mm (H)
Net Weight: 0.21kg
Environment
Ambient Air Temperature for Operation: 32…140 °F (0…60 °C)
Ambient Air Temperature for Storage: -40…185 °F (-40…85 °C)
